Conforming with ISO2858 Standard means dimensional interchangeability with other makes of pumps, manufactured to the same international standard, however because of design superiority Monoflo ISO-Magna exceed the performance standard.
Superior hydraulic design and manufacturing processes, make ISO-Magna a robust pump, ensuring extended life and performing at significantly higher efficiencies and greater performance at reduced running costs and minimum maintenance.
Depending on pumping requirements and specific applications, ISO-Magna can be engineered in various material executions, and seal types to meet application needs.
PN16 suction & discharge flat-faced flanges available in BS standard(4504-1969 Table 16/11) or DIN standard(2501/P1PN16).
PN25 rating available as option.
Incorporated with lifting eye to simplify removal of the entire rotating element including the bearing housing during maintenance.
manufactured in high-grade cast iron as standard with integral cast feet and vertical centerline discharge for automatic self-venting. Depending on requirements, casings in ductile iron or stainless steel(SS316) are also available as option.
The hydraulically & dynamically balanced impeller is taper-mounted and keyed to shaft for positive drive during operation. The taper-mount design of the impeller easy removal from shaft during servicing & maintenance.
Heavy duty designed shaft for minimum deflection, smoother running and longer bearing life. Machine in high quality 420 stainless steel material as standard. Also available in SS316 or duplex stainless steel as option.
Fitted as standard, design-rated "heavy duty" sealed for life bearings to ensure safe operation, and exceptionally long, trouble-free life. Lip seals and water flinger are incorporated to prevent ingress of dust & moisture. This significantly improves bearing life.
The mounting feet is integrally casted to the casing. This allows the whole rotating element and the bearing pedestal to be 'back pullout' for maintenance. without having to disturb the pipework.
Water transfer & pressure systems; central air-conditioning systems; fire protection; swimming pools & water feature applications.
Circulation for machine cooling, process water in paper& pulp, iron & steel mills and sugar industry; marine & shipbuilding; and other manufacturing processes.
Mine general water supply; mine dewatering; generation of power; mining process.
Irrigation; stock watering.
Clean water or slightly-aggressive liquid compatible to pump material of construction.
Maximum working pressure up to 16 bar, (with exception of models at 10 bar). Pressure rating up to 24 bar available as option.
Maximum capacity up to 250 litres/sec or 900 m3/hr.
Maximum discharge pressure up to 16 bar or 160 metres.
Temperature range of medium pumped, from - 15oC to 80oC. Higher temperature up to 105oC, with optional mechanical seals.
Maximum operating speed up to 2,900 r.p.m. at 50Hz and 3,600 r.p.m. at 60Hz.
